Marikina’s Bike and Parking Lanes

I had to navigate through Marikina’s streets in order to reach the Feliz Mall from the city’s downtown. Normally, I would have taken the more straightforward route that would have involved traveling along Marcos Highway. However, I couldn’t because it was my number coding day and the U-turn slots in the area are usually “swarming” with MMDA and Pasig City traffic enforcers. Marikina’s streets though were not part of the coding scheme and you only need to be familiar with their road network including which streets are one-way in order to navigate the streets properly.

The bike lane is on the left side of the one-way road and to the right of the on-street parking spaces. The parking lane is the left-most and curb-side.

This actually qualifies as an example of a road diet application. These could have easily been 2-way streets before but effectively 2 lanes have been allocated for traffic flow while the others are for parking and cycling. [Of course, hard-core cyclist will say only one lane was taken away from motor vehicles.]

These bike and parking lanes were implemented in connection with the Marikina Bikeways project that was initiated during the time of then Marikina Mayor Bayani Fernando in the late 1990s. The project was continued and maintained by succeeding administrations of the city and contribute to the city’s being more liveable compared to other LGUs. The reconfiguration of the streets make them safer and saner in terms of traffic flow where “traffic” is referred to as inclusive of all users.

The Ortigas Center bike lanes, complete streets and road diets

The MMDA recently stated they were planning to apply the road diet concept to EDSA by narrowing the current lane widths in order to add one lane per direction. While the idea seems to of good intention, the mention and application of road diet is flawed. I have previously shared an article on social media showing the definition and examples of complete streets:

What are complete streets?

Clearly, complete streets are for the benefit of everyone (i.e., inclusive) and not biased for motor vehicles. Here is a photo of F. Ortigas Ave. at the Ortigas Center in Pasig City showing the correct application of the Complete Streets and Road Diet concepts to an urban street. Note the elements for cycling and walking that are very prominent in the re-design of the street.

Protected bike lanes at either side of F. Ortigas Ave. at the Ortigas Center

We hope to see more of these re-designs in many other cities and towns in the Philippines. It is not a really difficult concept to apply or adopt as technically these are not complicated. However, there needs to be a change in the mindset of planners and engineers when they do these exercises considering how car-oriented our designs are. It is easy to say we want more people-oriented transportation facilities until it dawns on us how dependent we are on cars and resist the efforts to realise more sustainable designs.

The Julia Vargas Avenue protected bike lane

I thought I already posted an update on the Julia Vargas Avenue in Pasig City. It turned out I was only able to upload photos on my folder but wasn’t able to get to writing about the bike lane. And so we conclude the year 2018 with a positive post of something we would like to see more in 2019 and beyond. We are hopeful that the protected bike lanes along Julia Vargas Avenue, connecting C-5 with the Ortigas Center, will expand and that this example along those of its predecessor bikeways in Marikina and Iloilo would be replicated across the country particularly in highly urbanised cities.

A view of the westbound bike lane along Julia Vargas at the Ortigas Center. Note that the eastbound bike lane (visible in this photo) is not similarly protected vs. motor vehicle encroachments. It would be preferable for that lane to be protected, too. Parang bitin pa tuloy ang effort nila.

Another view of the protected bike lane along the westbound side of Julia Vargas Avenue in contrast with the obviously congested lanes available for motor vehicles.

The middle lanes of the carriageway are wide and can accommodate motorcycles though the latter always seem to prefer filtering or splitting the lanes. The median lanes are generally for low occupancy vehicles (less than 3 passengers) while the middle ones are for high occupancy vehicles (3 or more passengers) including UV Express vans and buses.

Happy New Year to all!

Katipunan bike lanes?

Here are photos of the bike lanes along Katipunan Avenue (Circumferential Road 5). The lanes are basically just marked with a solid green line but without any signs or pavement markings reinforcing this designation. The lanes are not protected ones like the example along the eastbound bike lane along Julia Vargas Avenue in Pasig City. And so, as expected, there are many motor vehicles encroaching upon the Katipunan bike lane including parked or standing vehicles as shown in one of the photos below.

The bike lane is derived from the outermost lane of Katipunan

Here is the bike lane along the southbound side of Katipunan at the approach to Tuazon Avenue. That’s a pedicab on the bike lane so one can easily appreciate the dimensions particularly the width of the lane.

Bike lane along the northbound side of Katipunan approaching Ateneo’s Gate 2

The bike lane along with the designated truck lane and motorcycle lane.

Here are cyclists using the lane past Ateneo’s Gate 3 and approaching the main gate of Miriam College

I’ll try to sketch a few recommendations into the photos as I have done in a past article:

On the Pasig HOV lane experiment

This can also be used for exercises I assign to my graduate and undergraduate classes when we’re on the topic of complete streets.

On the viability of bike lanes in the Philippines

I have been inserting topics on complete streets in the undergraduate and graduate courses I teach at university. Some students have also been researching on best practices and designs that they are supposed to apply to real world situations in Philippine cities. The results are still generally mixed but I like how my undergraduate students are able to grasp the concepts and apply them in the short time they have been ‘exposed’ to the concept. I thought my graduate students, most of them practicing engineers, found it more challenging to unlearn many of the things about street design they have learned from their schools including UP and DLSU, which I thought would have the more progressive programs in Civil Engineering.

Here are a couple of helpful articles that explain the business (economic) case for bike lanes. After all, the most persuasive arguments to convince LGUs to take on bike lanes will always be economics or business. That’s also how you can probably convince the business sector to pitch in and lobby for more active transport facilities especially in the downtown areas.

Jaffe, E. (2015) The Complete Business Case for Converting Street Parking Into Bike Lanes,, [Last accessed: 11/1/2018]

Flusche, D. (2012) Bicycling Means Business, The economic benefits of bicycle infrastructure,, [Last accessed: 11/2/2018]

One issue often brought up by opponents of bike lanes is that there are few references for bike lane design and operations in the country. Perhaps the only really comprehensive example is Marikina City though I know for a fact that the last three of their mayors (yes, including the incumbent) is not so keen about their bikeways. In fact, one mayor tried to dissolve the city’s bikeways office only to relent and allow it to exist but under one of its departments. Iloilo City is supposed to have some bike lanes but it is still more like a landscape architecture experiment than a fully functional system (sorry my katilingbans and panggas). And so we look to the more comprehensive experiences abroad for evidences of viability and success. The bottomline here is that I would rather ask how it can succeed here than state why it will not.

On the need for more facilities for cycling and ensuring they will be used for cycling

I read and hear a lot of comments about two particular items: pedestrian overpasses and bike lanes. Most of the comments call for pedestrians and cyclists to have priority over cars and for the latter to give way to pedestrians and cyclists every time. The hardline stance for some is for the pedestrians to be allowed to cross anywhere and for cyclists to be able to bike on any lane they choose to. Of course, the concerns about these are quite obvious and safety still calls for people, no matter what mode they choose, to use the appropriate spaces. What few actually discuss and delve into are design solutions to these problems. Many cite good practices elsewhere but stop at sharing these and not really going into in-depth and constructive discussions on how to implement these good designs here. Most of the time its just “the government must do this” and “the government must do like what (insert city or country) is doing”. Worse are those who tend to simplify it as an “architect vs. civil engineer vs. planner” kind of conflict. Playing the blame game doesn’t get us anywhere if we wanted the planning and design of transportation infrastructure improved.

Cyclists use the overpasses to cross the wide Marcos Highway between Pasig and Marikina. There are only 2 ramps, one each on either side of the highway and it partly occupies the sidewalk beneath. Could there be a better design for such overpasses?

Motorcycles using the bike lanes along Ortigas Avenue. How do we make sure that spaces are utilised according to their intended users? How do we design these spaces to include elements that will deter such incursions?

There are many references out there showing us what good design should be from the technical and social perspectives. Surely these can be taken up not only at the workplace for architects, engineers and planners but in schools where such principles are supposed to be learned and inculcated into the minds of future architects, engineers and planners.

On the need to increase NMT and public transport use

A recent report reinforces what many of us already probably know or are aware of – that we need to shift away from dependence on car use to more sustainable modes of transport in the form of non-motorised transport (NMT) and public transportation. Here is the article from the AASHTO Journal:

Global Climate Report Calls For Expansion Of ‘Non-Motorized’ Transport And Public Transit (2018)

There is a link to the report in the journal article. The report is conveniently available in PDF form and is very readable (i.e., not overly technical).

Incidentally, I was involved some time ago in a project led by the group Clean Air Asia (CAA), which involved several experts from across ASEAN as well as Japan that attempted to determine the necessary transport programs and projects in the region to stave off the projected increase in global temperatures. In all the scenarios evaluated, non-motorised transport (NMT) and a rationalised public transportation system By the term ‘rationalised’ I am referring to the use of higher capacity vehicles as against the taxis and tricycles that typically carry few if not one passenger. Here is a link to the final symposium for that study that has links to the materials presented:

The Final Symposium on the “Study on Long Term Transport Action Plan for ASEAN”

Here’s a slightly updated slide on the future image for a large city in the Philippines:
