Single ticketing at last?

Among the big news on transport and traffic in Metro Manila this weekend is the resolution by the Metro Manila Council (MMC) to adopt a single ticketing system for traffic violations in Metro Manila. It took some time for this to be realized and such a system should be favorable to motorists and LGUs alike. The biggest issue in the past was how to divide the revenues derived from the penalties imposed on erring motorists (though some quarters will deny this). Many MM LGUs balked at the original proposal of the MMDA that the agency should get the bulk of the revenues. The MMDA explained that their enforcers were and are deployed along most roads and manage traffic in most of Metro Manila. Perhaps they were right in proposing for a substantial cut of the total revenues as many LGUs were dependent on the MMDA for traffic management.

Following is the news article from the Philippine Star:

MANILA, Philippines – Metro Manila mayors have approved the resolution for the adoption of a uniform or single ticketing system for traffic violations in the metropolis.
Metropolitan Manila Development Authority (MMDA) chairman Francis Tolentino said the resolution was approved after a dialogue between Metro Manila mayors and Interior and Local Government Secretary Jesse Robredo at the Pasay City Hall last Thursday.
Representatives of transport groups – the Federation of Jeepney Operators and Drivers, Pangkalahatang Sanggunian Manila and Suburbs Drivers Association, and Pagkakaisa ng mga Samahan ng Tsuper at Opereytor Nationwide – also joined the dialogue.
Tolentino said Robredo would present the resolution to President Aquino for approval.
“Without the single ticketing system, Metro Manila local government units (LGUs) and the MMDA use their respective traffic violation tickets. This runs counter to the 1995 MMDA Charter, mandating the MMDA to install and administer a single ticketing system,” said Tolentino.
He said the resolution paves the way for the implementation of a uniform traffic violation ticket bearing the MMDA logo and that of the 17 LGUs of Metro Manila.
“The uniform ticket will be issued by all traffic operatives within Metro Manila and shall be recognized metrowide,” he said.
Tolentino said a technical working group composed of the traffic heads of the 17 LGUs of Metro Manila, representatives of the Department of Transportation and Communications, Land Transportation Office, Land Transportation Franchising and Regulatory Board and the MMDA would be created to resolve the issues concerning the implementation of the unified ticket system.
The transport sector and the LGUs have until Feb. 2 to submit their comments and proposals on the matter, the MMDA said. – By Mike Frialde (Philstar News Service,

We look forward to the implementation of the single ticketing system for traffic violations in Metro Manila. Perhaps after the usual confusions and misunderstandings at the start of the integration, we will see a more systematic (and maybe stricter?) way of handling violations. This should, however, translate to better behavior among motorists as the system should influence how people drive. Otherwise, all the hype for single ticketing would have been to naught.

Perhaps the next single ticketing project should be for public transport fares?

Balete Pass (Dalton Pass)

Dalton Pass is named after a General of the US Army who led combined Philippine and American troops pursuing a retreating Gen. Tomoyuki Yamashita during the campaign for the liberation of the Philippines in World War II. It is part of the Pan-Philippine Highway and the Asian Highway network (AH-26). The section is also part of what is known as the Cagayan Valley road, which is the main highway access for the eastern part of northern Luzon. The northern part of Luzon Island is divided by the Cordillera mountain range with the Ilocos region in the west and Cagayan Valley in the east.

Following are photos taken a few years back during a trip to the city of Tuguegarao, Cagayan. I chose to go via land and using the Pan Philippine Highway out of curiosity about the towns and provinces along the way. The trip, after all, allowed me to go through the provinces of Bulacan, Pampanga, Nueva Ecija, Nueva Vizcaya, Isabela and Cagayan. At the time, it took us around 11 hours to travel to Tuguegarao where I promoted the graduate programs of the UP College of Engineering. This included two stopovers for late breakfast and late lunch.

National Historical Institute marker placed in 2005 relating (in Filipino) the events in the latter part of World War II during the pursuit of retreating Japanese forces from February to May 1945.

Balete Pass is located in the town of Bayombong in Nueva Vizcaya province. This market is for the viewdeck completed in 2000.

Stone marker with inscriptions in Japanese commemorating those who fell in the battles at Balete Pass.

Another marker in Japanese

Shrine dedicated to those who fell in the battles during World War II

Reverse curve section along Dalton Pass – being a major corridor means there’s a lot of truck traffic including tankers using the highway

Trailer tanker heading north along Balete Pass. The photo shows the foot of the hill where the view deck is located. The access road to the view deck is shown on the lower right. There are stores on the left that cater to tourists and other travelers.

Another marker is located near the foot of the view deck. There were no other visitors except us so we were able to park easily. From where we parked, one had to walk along the stairs to the view deck.

The view deck allowed for great views of the surrounding areas and like the one along Kennon Road in Baguio, one could see all around for kilometers away. This is a photo of a landslide/rockslide prone section where a concrete roof was built over the section to protect motorists and preserve the road.

Transport and health

The University College London (UCL) recently released a publication with the title “Transport, Physical Activity and Health: Present Knowledge and the Way Ahead.” It is authored by Roger L Mackett and Belinda Brown of the Centre for Transport Studies, University College London. The material presents an excellent discussion relating travel behavior (like the preference for car use or taking public transport) to physical activity. It should be a good reference for those seeking to explore the link between healthy living and transport and a study that can be replicated in other countries. It should be of interest to cities looking at ways to promote public transport, walking and cycling (sustainable transport). Perhaps our own Department of Health (DOH) should collaborate with the Department of Transport and Communications (DOTC) to put in the local figures so we can determine how much our dependence on cars is affecting our health especially in our cities. The outcomes should further reinforce the need to put up infrastructure to encourage people to leave their cars. Perhaps the more progressive cities or the MMDA could also look into such studies so that we can have a firm foundation for appreciating the benefits of a good transport system and healthy cities.

Barriers at U-turn slots

The MMDA has received a lot of flak from motorists and road safety experts regarding traffic schemes in Metro Manila  This is but natural and one can say that “it comes with the territory,” considering that the agency handles much of the traffic management in MM and a lot of criticisms are actually of the nitpicking kind. Some matters, however, while appearing at first to be minor are actually details that should not be missed particularly if the end result may mean a matter of life or death.

Details pertaining to the U-turn slots, for example, are often lost in the big picture approach of looking at the facilities as solutions to problems of congestion. In striving for faster speeds, the case for safety is often overlooked. In striving for continuous flow, the case for disciplined movement at intersections is discarded. And in imposing the scheme along roads not designed for it, the case for sound, safe design is sacrificed. The latter is demonstrated in the case of barriers used to delineate the U-turns, allocating space for turning vehicles while constricting that which is for others. For the barriers to be practically immovable, these were cast in concrete and painted to enhance visibility. In certain cases, reflectors were added to further increase visibility particularly at night-time. Previously, many barriers were made of plastic and filled with water for them to have weight. These eventually gave way to the more durable concrete barriers, although both were of the same shape and size and occupied significant space when laid out.

Recently, the MMDA installed plastic bollards at several U-turn slots, replacing the concrete barriers there. This was a welcome development that allowed the freeing up of space occupied by the massive concrete barriers. Moreover, while delineating the U-turns, the bollards will be more forgiving for motorists who could be involved in crashes involving these. Concrete barriers are not so forgiving and may cause a vehicle to overturn if not stop abruptly and highly likely to be causing serious injuries if not death.

Typical concrete barriers near the foot of the Katipunan flyover across Aurora Boulevard – these are what will greet motorists speeding through the flyover and has been the bane of many who have crashed into these barriers (overspeeding? drunk? sleepy?). The barriers eat-up a significant portion of the middle lane and requiring drivers to swerve to the right and along the path of other vehicles. Plastic bollards have been installed but the concrete barriers remain and still pose dangers to motorists.

Plastic bollards along Katipunan at the U-turn slot across from the Miriam College main gate – these are more forgiving in that it will cause damage to a vehicle but will not stop it on its tracks delivering potentially fatal injuries to occupants. A plastic jersey barrier can be seen at the end of the median island at the left side of the photo. Such were usually filled with water to increase their weights to avoid them from being displaced from their locations.

There are other alternatives that may be installed and not just for U-turns, but also for public transport bays, medians and other applications. Some bollards may be collapsible, recovering (standing right up) after being bumped or ran over by a vehicle. Perhaps the MMDA should look into such options and other details more often while also proactively seeking for suitable, not necessarily novel, solutions to our traffic problems.

The Marcos Highway predicament

Just when I thought I’ve experienced the worst traffic jams along Ortigas Avenue Extension (De Castro to Junction) last year, I am greeted with even worse congestion along Marcos Highway as 2012 began. I have featured this highway in previous posts first on August 24, 2011, then in September 2, 2011, again in September 13, 2011, and then as late as December 18, 2011, as I have been able to basically monitor the progress of pavement “re-blocking” and drainage works along this highway (I live in a subdivision along the highway.). The project stretches from the Santolan area near the Marikina River to Masinag Junction, and affecting traffic in at least 4 cities (Quezon City, Marikina City, Pasig City and Antipolo City) and 1 major municipality (Cainta). The problem, it seems to me, is that the contractor seems to be behind schedule and is now trying to make up for lost time by practically digging up entire sections of the highway without first finishing the job in other sections they have already started rehabilitating. In fact, there are sections that already have new concrete pavements that are still inaccessible to traffic despite already over 2 weeks of curing time! The concrete barriers preventing vehicles from using these sections occupy about a fourth of the adjacent lanes, contributing to the reduction of what is already limited road capacities for the high volume of traffic along Marcos Highway.

I am aware of the traffic management plan for the highway as it is posted online at the DPWH website. But this is something that is on paper (or online) and one that seems to have been thrown out the window given the discrepancies with what’s on the plan and what we actually see and experience on the ground. The current work along the highway has effectively turned the stretch from Filinvest East to Santolan into a sort of slalom or obstacle course that has led to much inconvenience to commuters and motorists. Factor in the wasted fuel and the resulting emissions due to the congestion and you have economic losses piling up everyday.

I took the following photos I took one late weekday afternoon only this week as I traveled from Masinag to Imelda Avenue. The photos clearly show the work in progress along the highway that has been that main cause of congestion throughout most of the day.

Beginning of section being rehabilitated with work concentrated on a middle lane in front of the Marian Memorial (funeral) Chapels along Marcos Highway. Note the barriers on either side of the lane and the heavy equipment. Notice, too, the few people working on this section. Vehicles will have to split into two streams, one on either side of the affected lane.

End of the lane mentioned in the previous photos. There is a gap between this affected lane and the next one (start is indicated by the red barrier downstream in the photo) allowing vehicles to weave along sections between work sites.  The pick-up in the middle of the photo is doing just that – shifting from the shoulder lane to the median lane.

This is again the end of the section Unfinished section is flooded due to the sudden rainfall that afternoon in the area. Many sections have already been filled with base layer material and compacted. However, I am wondering why the contractor has not poured concrete when I reckon it has already taken enough time for consolidation of the base layer. From the same photo above, you can see the beginning of another section under rehab, but this time two lanes (inner lanes) are closed to traffic on one side of the highway. There are 2 other lanes also closed to traffic on the other side of the median island.

Despite the completion of re-blocking for the median lane, it is still closed to traffic. Meanwhile, it has taken a significant amount of time since they dug up the middle lane shown in the photo and where the section should have been ready for concrete but with the water collecting after the sudden rains that afternoon. Notice the hazards posed by the concrete barriers along the highway.

Section along the westbound direction of the highway and across from Town & Country subdivision shows 2 lanes affected by the pavement rehab works and only 2 lanes available to traffic.

It is really quite difficult to offer solutions in this case considering so much work still to be done in order to meet the March 28, 2012 deadline posted on the project billboards along the highway. For one, I do not know exactly what the reasons are for the delay of the project (perhaps a delayed release of funds?) and why the contractor has been unable to deliver according to schedule and plan considering the amount of time that was available to them. I do notice that there seems to be not enough people working on the project and that there seems to be no one working during certain times of the day when traffic is supposed to be lighter and fewer people to inconvenience. I did write that the contractor was doing a decent job in managing traffic before including their good use of counterflows. That was months ago and it seems that the saying “you are only as good as your last performance” applies in this case where people will be scrutinizing the current state of traffic along Marcos Highway.

People do expect though that the combined efforts of the MMDA, local traffic enforcers from Pasig, Marikina and Antipolo, and personnel from the contractor to make a bigger effort to ease (manage?) traffic congestion during the critical periods. It’s very frustrating and disappointing, however, that instead of managing traffic or facilitating flow, most enforcers seem to be engrossed with enforcing the number coding scheme alone. This seems to be the case for Pasig and MMDA enforcers posted at Ligaya and the Metro East vicinity. Perhaps number coding should be the least of their concerns when traffic is already constricted because of their failure to manage the jeepneys clogging the Ligaya area as well as what seems to be a breakdown in the coordination among these enforcers and the contractor of the rehab works along Marcos Highway.

Gapan-San Fernando-Olongapo Road: San Fernando

The Gapan-San Fernando-Olongapo (GSO) Road stretches across 4 provinces in Central Luzon. The road starts from the City of Gapan in Nueva Ecija and passes through the towns of San Isidro and Cabiao before crossing into Pampanga through the towns of Sta. Ana, Arayat, and Mexico, and crossing the North Luzon Expressway (NLEX) and McArthur Highway along the City of San Fernando. After San Fernando, the road heads west through Bacolor, Sta. Rita, Guagua and Lubao. It exits Pampanga from Lubao and to Bataan via Dinalupihan, and finally to Olongapo City in Zambales. It is also known along major stretches as Jose Abad Santos Avenue.

The GSO used to be the only main route towards Bataan and Zambales from the North-South corridor defined by NLEX and McArthur Highway (also known as the Manila North Road). That was prior to the construction of the Subic-Clark-Tarlac Expressway (SCTEX), which stretched from Tarlac City in the north and through Concepcion before crossing to Pampanga. The tollway proceeds southwest through Clark (in Mabalacat and Angeles City), the towns of Porac, Floridablanca and eventually crossing into Bataan at Dinalupihan. The SCTEX finally connects to the Subic Freeport Expressway (SFX), which is also known before as the Tipo toll road.

One of the justifications for the Clark-Subic component of the expressway was the need for an alternate route between the industrial centers at Subic, Hermosa, Clark and Tarlac (Luisita?). Unfortunately, the projected rapid developments of those centers were not quite realized and traffic along SCTX remains light for most of the time. Congestion apparently only occurs at the Clark exit where the toll plaza capacity is not enough to accommodate vehicle arrivals. To compound the situation, the national government improved the GSO, increasing its capacity and therefore making this free road a viable alternative to the SCTEX when traveling between Pampanga and Zambales.

Following are photos taken quite recently along the GSO Road and at San Fernando. I will post other photos later, featuring sections along other towns.

Roundabout at the interchange with the NLEX on the west side of the tollway

GSO section leading to what most people think is already San Fernando City proper. The old city center is actually further south along McArthur Highway and is an example of a traditional “bayan” with the municipal/city hall, church and market clustered together.

Overpass along GSO Road over McArthur Highway – prior to the construction of the overpass, traffic junction was the main cause of congestion in the area.

There are actually two overpasses, one beside the other, and each having two lanes and dedicated to one direction of traffic. As can be seen in the photo, there are no shoulders or space for pedestrians. The double yellow also indicates no overtaking along the overpass.

The overpass structure is very similar to those constructed in Malolos, Bulacan and Iloilo City. Similar structures were proposed for a flyover along Quezon Avenue and crossing Araneta Avenue in Quezon City but an underpass is instead being constructed in that area.

After the overpass, travelers pass through an elevated section of the GSO Road. The section was constructed over an embankment that was part of the response on the infrastructure side for disastrous lahar flows of the 1990’s. At the time, many sections of the GSO Road were destroyed by lahar generated by the eruption of Mt. Pinatubo in 1991.

The concrete barriers are quite low and definitely not enough to prevent even a car from taking off from the road (in case of one going out of control) and unto the houses below. The photo above clearly shows how high the carriageway is with respect to the adjacent areas. Notice, too, the narrow strip serving as a shoulder for the road.

8There was significant congestion almost immediately after descending the overpass and along the westbound direction of GSO Road. It took quite a while for us to reach the cause of the congestion – GSO Road’s intersection with Lazatin Boulevard.

The junction is not signalized (no traffic lights) and manned by enforcers who appear to have no formal training in traffic management. I say so since they were applying the “buhos” system of attempting to dissipate queues from each approach (there were 4) without considering that in the process, longer queues were forming along the major road (GSO). Also, it seemed to us that the enforcers were prioritizing traffic along Lazatin when it was obvious that GSO was already congested.

Traffic was practically free-flowing after passing the GSO-Lazatin junction. There were 4 lanes (2 per direction) and sufficient shoulder space on either side of the highway.

Carlos P. Garcia Avenue

I really haven’t written much about the other segments of Circumferential Road 5 (C-5), choosing to write about the Katipunan Avenue stretch from Aurora Boulevard to Magsaysay Avenue (UP Diliman). C-5 is officially named Carlos P. Garcia Avenue or C.P. Garcia Avenue after the 8th President of the Philippines. C-5 though is more commonly known by its many names for at least 3 long stretches of the road: Katipunan, E. Rodriguez, Jr. Avenue (Boni Serrano Ave. in Quezon City to Pasig Boulevard, Pasig City), and C.P. Garcia Ave. (Pasig Blvd. to SLEX/East Service Road). Following are a few recent photos along C5 along C.P. Garcia Ave. in Taguig.

U-turn flyover at C-5/Kalayaan is among the much maligned projects of a past MMDA administration. There is supposed to be 3 lanes between the columns but the pavement conditions and relatively narrow lanes would usually accommodate only 2 vehicles at a time especially when one is a truck. Should it be demolished to give way to the original scheme proposed by the DPWH for the intersection? The current grade separation project at Quezon Ave./Araneta Ave. will eventually show whether such a scheme could have been better for C5-Kalayaan.

The pink column is a remnant of what used to be a pedestrian overpass at C-5/Kalayaan. There used to be a two span overpass in the area that has since been That’s the second elevated U-turn downstream that is utilized by traffic from Kalayaan (Makati) to Taguig (through traffic if the intersection was not closed to such) and to Pasig (left turn traffic).

Approach to the construction site of an off-ramp/overpass from Bonifacio Global City. The flyover is supposed to ease traffic from BGC to C5-northbound currently concentrated along the overpass at 26th Street and Market! Market!

Close-up of the flyover construction. The temporary columns and barriers in the middle of C5 can be quite tricky even during the day and the space is just enough for 2 cars to fit through the middle lanes. With trucks its again a different situation as they often require more space given the behavior of their drivers encroaching upon the adjacent lanes.

Overpass from Market! Market! and along 26th Street. The pedestrians using the overpass and crossing to and from Target Street in old Taguig are undisciplined and do not follow traffic enforcers at the intersection with the service road. This leads to a high likelihood of pedestrian vs. vehicles collisions due to the conflicts in that area.

The walls at the right side of the highway were constructed to separate C5 from the service roads on either side of the highway. These service roads are notorious for being used by residents of the areas along C5 for parking and jeepneys typically stop anywhere along the road to drop-off or pick-up passengers. Also, there are many incidences of people crossing C5 without care of their safety. Also, there have been cases where some vehicles have been reported to have been stoned by anonymous persons (probably from the informal settlements along the highway). The walls were interventions that are supposed to control such behavior and keep C5 as unimpeded as possible.

Despite objective for the walls, there are many breeches and these result in still a lot of jaywalking across C5 and jeepneys stopping to pick-up/drop-off passengers.

A persistent issue along C5 pertains to the operations of jeepneys along the highway. There is a tendency to congregate at the designated loading/unloading areas that coincide with the pedestrian overpasses along the highway. Jeepneys typically occupy 2 lanes including the shoulder lane adjacent to the wall. The same behavior occurs at wall breeches often causing bottlenecks along the highway.

Afternoon jam along Katipunan

The northbound direction of Katipunan Avenue is usually congested from mid-day to early afternoons on weekdays. The congestion is caused by several factors including truck traffic and school generated traffic. Katipunan is part of a truck route along which trucks are allowed during the perceived off-peak periods (i.e., not during the morning and afternoon peaks). There are many schools in the area including two major universities (UP and Ateneo), a college (Miriam), and several other schools that generate a lot of vehicular traffic around this time mostly from their grade schools or pre-schools. There are also a lot of activity along the stretch from Ateneo to C.P. Garcia due to the commercial establishments especially the restaurants that attract quite a lot of patrons during the extended lunch period (typically from 11:00 AM to 2:00 PM).

Congestion stretches onwards and may reach past the other end of the overpass towards the Blue Ridge area. The 5-lane section (3 from the flyover and 2 from the at-grade section) narrows to 3 lanes at this section to accommodate the U-turn slot past Ateneo’s gate 2 – an classic case of a bottleneck.

The SM Blue condominium construction is visible in the background of this photo. Although the U-turn slot only has about 1.5 lanes worth of space, the concrete barriers cover the remaining space of a lane, thereby reducing effective capacity for the road section.

A tarpaulin sign stating Ateneo’s position questioning Notice the concrete barrier used to delineate the U-turn slot that obviously has seen better days. This location is probably among the most dangerous sections along Katipunan (and C5 in general). This has been site of many fatal road crashes. During early mornings, motorists speeding along Katipunan (uncongested during the unholy hours) and descending the flyover often miscalculate or are suprised by the U-turn slot and its unforgiving barriers. The damage on the barrier in the photo is a “souvenir” of sorts from it being a witness to a crash.

Muelle del Rio

The Muelle del Rio is a riverside road that stretches from Quezon Blvd. (from the ramp of Quezon Bridge) to Plaza Mexico in Intramuros. The road passes under the McArthur and Jones Bridges that cross the Pasig River, and behind buildings such as the Manila Central Post Office, the National Press Club, the Philippine Chamber of Commerce and Industry, and the Bureau of Immigration.

The stretch from McArthur Bridge behind the Manila Central Post Office is clear of squatters but there are many garbage, mainly plastics, strewn everywhere. There are people “residing” under McArthur Bridge and these homeless people have only their carts or cardboard boxes to protect them from the elements.

The lamp posts along the road look like they were inspired by the capiz windows of old houses. The homeless include the individual pictured here who was washing clothes using the flowing water from various sources including a leaking water pipe. This section is often flooded during the wet season due in part to its location and elevation with respect to the Pasig River.

The underpass at Jones Bridge is another section that is usually flooded during the wet season. A staircase connects the bridge and the riverside walkway cum park. The bridge is currently mentioned in news reports regarding the film “The Bourne Legacy” that will be shot in Manila. The bridge is an old one and considered a landmark in Manila. It has been the subject of many old photos and has been romanticized in paintings.

Vehicles parked along the linear park across the road from behind the Bureau of Immigration. The park is not supposed to be a parking facility but due to a lack of parking spaces for the Bureau and not too many people using the park anyways, parking was tolerated. Perhaps it is better than having such vehicles occupy precious road space. Further down the road, the red tile roof of a  Pasig River Ferry terminal is visible.

The Plaza Mexico Station of the Pasig River Ferry. the Ferry services were suspended last year due to many problems including the lack of passengers.

Plaza Mexico is only a stone’s throw away from the ferry terminal shown in the preceding photo and is already within the walls of Intramuros. Among the historical buildings in the vicinity are the Intendencia, Almacenes and the Aduana, which were buildings from the Spanish Period. Some are currently being restored as part of a heritage initiative in Manila spearheaded by the Intramuros Administration.

Some thoughts on airport parking for NAIA T3

I had another unpleasant experience parking at NAIA Terminal 3 just before Christmas. It seems its getting more difficult to park at the airport every time and authorities have yet to address the parking problem despite the solutions staring them in the face. I would like to believe that the typically higher demand for parking during the Christmas season can be accommodated if the available parking space can be managed and equitably allocated for users of the terminal.

Queue at the entrance to the airport – the guards were still inspecting each vehicle but they had to wait for these to inch towards them at the inspection point.

While the signs seem to suggest different parking facilities for arrivals and departure, there is actually one large open parking lot located in front of Terminal 3. This lot is segregated among airport taxi services, employee parking, overnight parking and general parking. Meanwhile, the parking  area to the right side of the ramp to the departure area is generally empty but for a few vehicles that are said to be owned by employees of the airport. This is quite odd considering they also have a lot of parking space for them

Everyone had to wait for the security to wave them through to to parking lot. Others were content with staying inside their vehicles while waiting to pick-up their passengers.

In the end, I had to rush to the airport terminal after parking my car as my wife’s plane was already arriving. I wasn’t able to take more photos of the parking situation that day but knew I had other opportunities to do so in the near future. That future was when I was back again recently at Terminal 3 when I drove someone to the airport for an outbound flight after the Christmas break. The queue at the gate was much better and we were able to enter the parking area without a glitch. There were many spaces available but these were mostly along the fringes of the lot, with some requiring a few minutes walk to or from the terminal.

View from the inspection gate with the on-ramp for the departure level to the right and the driveway to the parking and arrival areas to the left.

The way to the arrivals driveway (right) and the parking lot (left) was unlike the condition shown in the earlier photos taken just before Christmas.

There was a sign stating that the overnight parking area was full. The overnight parking area for those who opt to leave their vehicles until their return is actually the driveway on the right side of the photo that eventually leads to the on-ramp for the multilevel parking building that until now has not been opened for various reasons. To the left is the driveway to the parking lot.

Those vehicles lined up in the photo are not part of a queue for arrivals. These are parked along the driveway designated for overnight parking.

Meanwhile, these are vehicles at the parking area designated for the general public.

There seems to be a lot of signs for “Employees Parking” when airport authorities should prioritize space in this area for passengers and well-wishers. There are other under-utilized areas better suited for employees. I also wonder just how many employees actually have cars.

Turning towards the exit from the parking facility, one is greeted by more vehicles parked along the curbside (both sides of the driveway, actually). The fence separates this driveway from another that leads to the ramp to the multilevel parking building that is visible on the right side of the photo. This latter driveway also has vehicles parked along its length, which is allocated for overnight or long term parking. Above is the ramp from the departure level.

In this photo, the ramp to the multilevel parking facility can be seen clearly and is occupied by parked vehicles. I still wonder how long it would be and what it would take before NAIA Terminal 3 finally makes the parking building available for use of the general public when, according to some sources, there are no structural issues barring the use of the building. Meanwhile, there is already an obvious demand given the evolving preferences of travelers with their own vehicles.

Motorcycle parking at the fringe of the parking. This is actually another driveway utilized instead for motorcycles.

The layout of the open parking lot at Terminal 3 can be seen via Google Earth as shown in the image below. The area designated for public parking (center to right before the off ramp from the departure level)  is conspicuously full while there seems to be a lot of spaces available in the area allocated for taxis and airline and airport employees (left in the image and prior to the on ramp to the departure level). There is also a relatively spacious open lot to the left and adjacent to the terminal building itself. This seems to be reserved for employees (again?) and VIPs. While the last area may be allocated for employees and VIPs, I would like to point out that more parking spaces should be allotted for travelers and well-wishers. Questionable for me is the allocation of so many spaces for taxis and vans that seem to be using the lot as their depot. I seem to remember that these public utility vehicles should have their garage somewhere and not necessarily at the airport where they seem to be lording it over “regular” taxis. These airport taxis charge significantly higher if not exorbitant rates compared to the typical taxi and to some, their preferential treatment at the airport is at the expense of passengers and well-wishers who certainly deserve better public transport service.

Layout of NAIA Terminal 3 (image from Google Earth)

In the image above, the building with the light-colored roof to the right of the terminal building is a multilevel parking facility. The parking building is directly connected to the terminal and is accessible via the southeast wing of the terminal. I am not aware of the capacity of this facility but based on what one can see from the outside, its 5 levels should be able to accommodate quite a lot of vehicles and offer other opportunities for business (e.g., car wash, small shops, etc.) much like what is already available in similar facilities found in shopping malls.

[Note: An news article appearing on January 27, 2012 states that the parking building has a 2,000 car capacity while the open area can hold 1,200 cars. I assume these numbers refer to the number of spaces and do not include waiting or circulating vehicles.]
